2014 Buell EBR 190RX
|
Make Model |
EBR 1190RX |
|
Year |
2014 |
|
Engine |
Liquid cooled, four stroke, r72° V-Twin, |
|
Capacity |
1190 cc / 72.6 cu in |
| Bore x Stroke | 106 x 67.5 mm |
| Compression Ratio | 13.4 :1 |
|
Induction |
Electronic Fuel injection with 2 port injectors and 2 showerhead injectors |
|
Starting |
Electric |
| Exhaust | Primary + Secondary |
|
Max Power |
185 hp @ 10600 rpm |
|
Max Torque |
101.6 ft-lbs.137.8 Nm @ 8200 rpm |
|
Transmission |
6 Speed |
| Primary Drive Gear Drive | 36/65 |
| Final Drive | 520 Z-ring chain, 16/41 |
| Gear Ratio | 1st 2.46 2nd 1.75 3rd 1.38 4th 1.17 5th 1.04 6th 0.96 |
| Clutch | Hydraulic actuation, vacuum operated slipper |
| Rake / Trail | 22 / l 3.4″ -86 mm |
| Frame | Aluminum frame with integral fuel reservoir |
| Swingarm | Optimized stiffness aluminum |
|
Front Suspension |
Showa, inverted big piston front forks |
|
Rear Suspension |
Showa, single shock without linkage |
|
Front Brakes |
386mm (15.19in.) Single perimeter rotor, 8 piston inside-out caliper |
|
Rear Brakes |
Single 220mm (8.66in.) Disc, 2-piston Hayes Performance Brakes Caliper |
| Front Wheel | 17 x 3.5 Aluminum |
| Rear Wheel | 17 x 6.0 Aluminum |
|
Front Tyre |
Pirelli Diablo Rosso Corsa 120/70 ZR-17 |
|
Rear Tyre |
Pirelli Diablo Rosso Corsa 190/55 ZR-17 |
| Rake / Trail | 22.4° / 96.5mm - 3.80in |
| Lean Angle | 55° |
| Dimensions | Length 2040mm. / 80.3in Width 737mm / 29.0in. Height 1110mm / 43.7in. |
| Seat Height | 826 mm / 32.5 in |
| Ground Clearance | 120mm / 4.7in. |
|
Wet-Weight (No Fuel) |
190 kg / 419lb |
|
Fuel Capacity |
17 Litres / 4.5 gal |
